MPC-1700 Portable Workstation

Ruggedized System Chassis with 17" LCD and Expansion Slots

rugged lunchbox portable workstation MPC-3900 with dual processor, 20 inch UXGA LCD screen



MPC-1700 back side view.

  1. Cooling fan for add-on card area ventilation.
  2. Cooling fan for hard disk drive bays.
  3. Internal drive bays supporting two 3.5" hard disk drives.
  4. Slim-type optical drive and floppy drive spaces.
  5. Expansion card guides. Four full length expansion cards are supported.
  6. System board area. A Micro-ATX motherboard is installed in this illustration.
  7. Drive spaces for one 5.25" disk drive. Use it for optical disk drive or removable hard disk drive carrier.
rugged lunchbox portable workstation MPC-3900 with dual processor, 20 inch UXGA LCD screen



MPC-1700 back side view with power supply and stabilizer bars.

  1. 620-watt ATX power supply for 110~240 VAC 50~60Hz input.
  2. Stabilizer bars..
